Discharge Hose Diesel-DN 25

Discharge Hose Diesel-DN 25

Item No: 23155 950

Technical data
Connection 1: G 1″ male
Connection 2: G 1″ female with sleeve nut
Total length (m): 4
Inner diameter (inch): 1″
Inner diameter (mm): 25
Outside diameter (mm): 37
Material outer side of hose: SBR is abrasion-resistant and weatherproof
Material inner side of hose: NBR swelling-resistant, lixiviation-resistant and
freeze-resistant, not hardening, corresponds to
material NBR 1 of EN 12115
Carcase: two stretch resistant textile reinforcements
Colour of inner and outside
material: black
Low-pressure max. (bar): 0,5
Operating pressure max. (bar): 10
Material of connection parts: AlSi 12 (sea water resistant)
Material of seal: NBR 70
Design of sealing: O-ring
Weight (kg): 2,8
Specification
Marking: Acc. to DIN
low increase of volume under pressure
ideal as hose for reels

Hose connection by cap-nut screw connection

All Products 2 years warranty.
