FMT MOBIFIxx Diesel Transfer Pump 12 Volt

diesel transfer pump, DC diesel pump, fueloil transfer pump

FMT MOBIFIxx Diesel Transfer Pump 12 Volt

Item No: 23404

12 Volt DC Diesel Transfer Pumps Made in Germany

Technical data

Connecting cable with battery terminal clips, length (m) / (ft): 3 / 10

Connection suction side: G 1'' female

Connection discharge side: G 1'' female



Hydraulic data

Pump design: vane pump, selfpriming

Delivery rate under free discharge up to (l/min) / (gpm): 35 / 9.2

Suction height up to (m) / (ft): 3 / 10

Discharge pressure up to (bar) / (psi): 1,6 / 23.2

Pumping media: fuel oil and diesel



Motor data

Insulation class: F

Highest permissible limit temperature (°C) / (°F): 155 / 311

Voltage (V): 12 V DC

Power consumption (A): 19

Power (W): 230

Fuse (A): 25 A plug-in fuse

Duty cycle (min) under free discharge max.: 180

Run time (min) when dispensing valve is closed max.: 2

Torque (Nm): 0,38

Rotation speed (rpm): 3000

Type of construction: IMB 5

Safety class: IP66

Materials of parts in contact with liquid

Seals: FKM (Viton®)/NBR

Pump housing: AlSi 12 (sea water resistant)

Rotor: GG 25

Vane: POM

Dimensions LxWxH (mm) / (inch): 270 x 120 x 120 / 10.6 x 4.7 x 4.7

Weight (kg) / (lb): 5 / 11

Specification

● Vane pump, with integral bypass

● On/Off switch

● Fuse

● Siphon protection acc. to WHG (German government regulation for environmental

care), continuously active



● Installation of flowmeter NUMERIxx
